Mass XS-Search using Cache Attack

I was researching all over Google for vulnerable endpoints that allow a malicious third party to obtain sensitive information about the user. I found them so many that I couldn’t decide whether to report all of the vulnerable pages as a one report or maybe split them as separate ones. The impact varies from retrieving the private book collections to obtaining all the user’s contacts char by char. After that struggle, I decided to include all of the endpoints (excluding one I already reported b/124326006) in this report. I am aware that these reports might not be treated separately but I believe that you will review the overall impact very closely and evaluate whether some of the vulnerabilities could be split into separate pieces or not.

The vulnerable websites:

  1. My Activity: myactivity.google.com
  2. Google Mail: mail.google.com
  3. Google Search: google.com/search
  4. Google Books: books.google.com
  5. Google Bookmarks: bookmarks.google.com
  6. Google Keep: keep.google.com
  7. Google Contacts (old version): google.com/contacts
  8. YouTube: www.youtube.com

Overall impact

A regular user of Google Products can have their sensitive information exposed when visiting a malicious website. The example information that could be leaked is as follows:

PoC

I have prepared a joint Proof of Concept for all attacks: https://terjanq.github.io/Bug-Bounty/Google/cache-attack-06jd2d2mz2r0/poc.html. I tried to keep it as human-friendly as possible so I encourage you to read the source code to better understand the mechanics behind each attack.

Attack

All of the presented attacks depend on detecting whether the resource has been loaded by abusing Error-Based Caching Attack. The attack has been invented by Eduardo and can be read here https://github.com/xsleaks/xsleaks/wiki/Browser-Side-Channels#cache-and-error-events. To not waste any more time I will just step into describing each attack and try to draw the brief impact.

I. My Activity

Vulnerable resource:
Depending on the search results different resources are being loaded and one of them is the image: https://www.gstatic.com/history/static/myactivity_20190212-0122_1/images/no_results_gm2.png.

Impact
Along with the visited webpages, the example information that can be leaked is:

The impact and the attack is the same as in another issue b/122677661

Steps to reproduce

  1. Access the PoC
  2. Find My Activity section
  3. Fill the website you want to check if visited. Use " character to match the exact expression and logical operator OR to make queries more efficient.
  4. Submit the form

Video: https://youtu.be/Gz7OPlhLzNE

II. Google mail

Vulnerable resource
Again, depending on the results different resource is loaded and that is: https://www.gstatic.com/images/icons/material/system/1x/chevron_left_black_20dp.png

Impact
With help of advanced search (https://support.google.com/mail/answer/7190?hl=en) available in Google Mail it is possible to expose information such as

Tweaks
It is possible to use logical operators to make the binary-search possible and therefore to effectively search for information, e.g. 1234 OR 1235 OR 1236 .... I managed to search for ~250 words at the same time.

Steps to reproduce

  1. Access the PoC
  2. Find the section Google Mail
  3. Insert the message you want to search for
  4. Submit the form

Video: https://youtu.be/H3JTx0JhAng

III. Google Search (personal)

I have already reported this one. More info can be found here b/124326006

Video: https://youtu.be/nQJHGHw94fM

IV. Google Books

Vulnerable resource
No surprise. Depending on the search results additional resources are being loaded and two of them are:

Impact
Exposing user’s

The impact is very similar to the report b/123482975

Steps to reproduce

  1. Make sure to have some books you want to search for
  2. Access the PoC
  3. Find the Google Books section
  4. Fill the book title you want to search for and shelf id
  5. Submit the form

Tweaks
The attack uses another vulnerability I had found and described in the mentioned report and that is https://books.google.com/books?uid=vulnerability&q=hack. When accessing that URL the results for the logged user will be displayed without the need of knowing their id. Otherwise, the attacker would have to know that value.

Video: https://youtu.be/thRWVw24srM

V. Google Bookmarks

Vulnerable resource
Here, the different resource is https://ssl.gstatic.com/ui/v1/star/star-lit4.png which shows up when there are search results

Impact
This vulnerability allows the attacker to obtain information about bookmarked websites by the user.

Steps to reproduce

  1. Access the Poc
  2. Find the section Google Bookmarks
  3. Insert the website you want to search for
  4. Submit the form

Video: https://youtu.be/bMzFRZfxMF8

VI. Google Keep

Vulnerable resource
The resource here is quite different this time. I noticed that additional font is being loaded when there are search results and that is https://fonts.gstatic.com/s/googlesans/v11/4UaGrENHsxJlGDuGo1OIlL3Owp4.woff2

Impact
Exposing user’s private notes at https://keep.google.com

Steps to reproduce

  1. Access the PoC
  2. Find the section Google Keep
  3. Insert the content of the note you want to search for
  4. Submit the form
  5. Prepare not containing trjnq and click on the button find secret
  6. Wait for the results

Tweaks
The attack allows obtaining information character by character as presented in the video included below. It allows the attacker to dump any information that can be accessed on the website and the impact is almost as it was XSS Injection.

Video: https://youtu.be/naPmFYsHRcI

VII. Google Contacts

Vulnerable resource
Similar to the previous attacks, a lot of vulnerable resources can be found. Two of them are:

Impact
Exposing user’s contacts including:

Steps to reproduce

  1. Access the PoC
  2. Insert the details you want to search for (phone number/name/email)
  3. Submit the form
  4. Create a new contact with a name starting withtrjnq_ and tag it with the start
  5. Click on the button Find starred contact trjnq_...
  6. Wait for the attack to finish

Tweaks
Firstly, the attack only works on the old version of contacts. When a new user accesses the https://google.com/contacts they will be redirected to new version https://contacts.google.com/. I managed to bypass this obstacle by forcing the user to use the old version by appending the hidden parameter cplus=0 (https://www.google.com/contacts/u/0/?cplus=0).

Another tweak is that the attack allows obtaining information character by character as presented in the video included below. It allows the attacker to dump any information that can be accessed on the website and the impact is almost as it was XSS Injection.

Video: https://youtu.be/F8Kuj7B4tMo

VIII. YouTube (watching history)

Vulnerable resource
This one is tricky. The resources that depend on the search results on https://www.youtube.com/feed/history are video thumbnails. Each of them looks a little complicated, e.g. https://i.ytimg.com/vi/CU9Iafc-Igs/hqdefault.jpg?sqp=-oaymwEZCPYBEIoBSFXyq4qpAwsIARUAAIhCGAFwAQ==&rs=AOn4CLACWMy85SQ_D3b1STEV2-l7XeY8XQ because there are two parameters appended which seem to have unpredictable values. However, I found that when searching for a specific video using main YouTube search results with the same URLs. Hence, it’s possible to leak the information about the watched videos.

Impact
The user can have their watched videos exposed to the third-party applications.

Steps to reproduce

  1. Access the PoC.
  2. Find the section YouTube (watching history).
  3. Choose the video you want to check if watched.
  4. If not watched click on the URL from status and after some time try again.

Note that checking same video two times in a row can result in false-negative because caching system works weirdly. You can try to reproduce this and inspect it further.

Video: https://youtu.be/S-QEkOvljCQ
